Zero Latency. Low Bandwidth. Video Anywhere.

EdgeVis provides real-time video streaming from anywhere to anywhere - even over wireless networks - saving data costs by using 60% less bandwidth than standard technologies.

“Standards-based” video transmission systems struggle to deliver a quality service when operating over wireless networks. Video streams stall and break up, and delivering video with several seconds’ latency is the only way to deliver smooth frame rates.

In a world that is rapidly going wireless, and where users want to see, in real time, what is going on, EdgeVis Live is the answer.

EdgeVis Live is ideal for getting video from moving vehicles such as buses, trains or even ambulances, as well as those difficult-to-protect remote assets such as oil pipelines and power substations. With our rapid deployment kits, it is also ideal for safeguarding high profile events or protecting public safety.

Based on our patented TVI video compression technology, EdgeVis Live provides a secure, scalable video-transmission platform, able to stream video live from cameras to users over any, but especially wireless, networks.

Developed for the highly demanding world of military surveillance, where losing a video feed or even a few seconds' latency may be the difference between life or death, EdgeVis Live is now the proven choice for the most demanding users in the defence, law enforcement, transport, energy and public-safety markets in more than 30 countries worldwide.

For more information on what makes EdgeVis Live different see TVI technology page.



What is EdgeVis Live?

EdgeVis Live is a wireless distribution platform, based on our TVI video-compression technology. It is designed to allow organisations, for the first time, to provide a video-transmission capability, allowing users to access cameras anywhere in the world in real time. EdgeVis does this in a secure, cost-effective manner that is 60 per cent more efficient than using “standards-based” video-transmission technology.

EdgeVis Live extends up from entry-level wireless video transmission, to a fully fledged wireless video-distribution platform, designed for the world’s most demanding users.

Features Benefits
Reliable live video over standard wireless networks

Our patented TVI codec guarantees live video by understanding second-by-second performance of 3G, LTE and WiFi networks

Full control over frame rate and bandwidth of streamed video

Users can control the cost and quality of the live video stream, depending on operational needs and budgets

Multiple simultaneous viewers

Our server-based architecture allows many users access to a single camera so everyone can see what is happening

Full remote camera control

Zero latency PTZ camera control and user definable PTZ presets, wherever you are

Common viewing clients across multiple platforms

Consistent look and feel across desktop and wireless viewers, so the control room travels with you

High resolution video retrieval from the edge

Short and long-term full resolution video archives at edge, making sure you don't miss the critical detail

Location and mapping support

Real-time encoder GPS plotting on map display, giving you the "bigger picture" of what's going on

Support for specialist wireless comms bearers

Ability to utilise GPRS, satcom, Tetra, IP Mesh radios plus others to get video out … anywhere in the world

Video analytics plug-ins (available Spring 2016)

Sterile zone protection and face detection and classification plug-ins to add intelligence to your solution

Enterprise administration tools

Toolset providing enhanced security, user administration and data-cost management to maintain control






For more information see our TVI technology pages.

Our EdgeVis Range - Hardware Options

How do I buy EdgeVis Live?

We sell EdgeVis Live as software preloaded on specialist encoder hardware. Depending on the encoder hardware type, different variants of EdgeVis Live software are available (see below). An EdgeVis Live software licence includes the software running on the encoder hardware, EdgeVis server software and EdgeVis Client software.

EdgeVis Encoders EdgeVis Server EdgeVis Client

As well as supporting all existing TVI encoders, EdgeVis introduces a number of new encoders including a new HD-IP150 and updated mobile encoders supporting body-worn cameras.

A refinement on TVI Server, the EdgeVis Server application introduces an updated management interface that unifies account and licence management, plus a range of performance and resilience features.

EdgeVis introduces a new unified viewing client across Windows, iOS and Android that provides a common look and feel on all platforms.

What encoder hardware devices can I buy going forward?

EdgeVis Live is available on a growing range of encoders designed to cover the full range of standard and high definition, analogue and IP cameras. All encoders include video storage and cellular and wi-fi connectivity.

Encoder Key Features
EdgeVis IP Series



HD-IP150

  • Real-time 1080p video and audio streaming
  • Record up to two camera channels onto an internal HDD/SSD
  • Built-in 4G/LTE modem and GPS, support for external USB wi-fi
  • Support for many different IP cameras including Axis, Canon, Bosch and ONVIF


HD-IP250
  • High performance encoder (for US only)
  • Real-time 1080p video and audio streaming
  • Record up to two camera channels onto an internal HDD/SSD
  • Supports external USB 4G/LTE modem and wi-fi
  • Support for many different IP cameras including Axis, Canon, Bosch and ONVIF


HD-IP450
  • Real-time 1080p video and audio streaming
  • Vibration resistant with built-in vehicle mounting kit
  • Record up to eight camera channels onto a removable HDD/SSD
  • Built-in 4G/LTE modem, wi-fi, and GPS
  • Support for many different IP cameras including Axis, Canon, Bosch and ONVIF


EdgeVis - R Series

SD-R500

  • Rugged SD analogue camera-surveillance hub
  • Ruggedised IP67/Mil Std 810F rated enclosure with no moving parts for reliable, low power and covert operation to enhance LPI/LPD properties
  • Real-time SD video and audio streaming


HD-R700
  • Rugged HD-SDI and SD camera-surveillance hub
  • Ruggedised IP67/Mil Std 810F rated enclosure with no moving parts for reliable, low power and covert operation to enhance LPI/LPD properties
  • Real-time 1080p video and audio streaming



EdgeVis - Q Series

SD-Q600

  • Outdoor IP66 all-in-one city-centre use encoder
  • Real-time SD video and audio streaming
  • Built-in 4G/LTE modem and Wi-Fi
  • Local wi-fi download of recorded footage


EdgeVis - S Series
HD-S600
  • Single HD-SDI camera encoder
  • Real-time 1080p video and audio streaming
  • Includes both HD-SDI and composite analogue inputs, with multiple PTZ protocols supported
  • Record one camera channel onto 2 x microSD cards or external NAS
  • Built-in 4G/LTE modem, wi-fi, and GPS


S400
  • Rapidly deployable ultra-small form factor single camera encoder
  • Real-time video and audio streaming, also supports retrieval of high-res images
  • Constructed to accommodate high level vibration associated with vehicle deployment
  • Two built-in GPRS/3G/HSDPA modules (with SIM carriers)

EdgeVis - C Series
C310
  • Single SD analogue camera encoder
  • Real-time SD video and audio streaming
  • Single analogue input, with multiple PTZ protocols supported
  • Built-in 3G/HSPA+ modem, support for USB GPS
  • Integration into numerous third-party DVRs


Decoder Key Features
EdgeVis - Decoder
HD-D1000
  • Self-contained hardware to decode EdgeVis IP stream
  • Up to three decoder units can be physically combined to create a 1U 19” rack unit using supplied rack kit
  • Use USB keyboard to switch between up to 99 streams and take control of any PTZ attached camera
  • Ultra low-power, consuming average 30 Watts per channel
  • Designed for deployment in a central control room and supports either HDMI or composite displays

Our EdgeVis Range - Software Options

What EdgeVis Live software can I buy?

EdgeVis Live software is licensed by either the number of camera connections to a device (in the case of IP Series hardware devices) or by the encoder hardware type.

IP series devices must be now purchased with an appropriate licence to unlock different levels of features. Each IP series device requires one licence per attached camera and all licences for an individual encoder must be of the same type as per grouping above.

  EdgeVis Lite EdgeVis Enhanced EdgeVis Enterprise
Live Streaming Max 4CIF/D1 @ 8fps Max 1080p @ 30fps Max 1080p @ 30fps
Full-res retrieval N Y Y
Edge Recording N
Area of interest N Y Y
Audio transmission N Y Y
Alarm transmission N Y Y
GPS Fixed Live Live
SecureConnect N Y Y
Server Scalability N N Y*
Video analytics integration N N Y*



The features listed reflect the maximum capability supported by the licence and do not reflect the capability of the device it is used with. Please check that any device chosen has the corresponding hardware capability. *Features due in future software release.

Existing TVI Customer?

EdgeVis Live is the new name for Digital Barriers' TVI technology, now established as the secure, real-time wireless video-streaming technology of choice for the world's most demanding organisations.

As an existing customer of TVI, you are already familiar with key technology that underpins the EdgeVis solution.

This new and exciting development for TVI, launched as EdgeVis, provides new features designed to improve usability, intelligence and scalability that build on all of TVI's proven capabilities.

These new features include:

  • A completely re-engineered user application providing a single-user application, running on Windows, Android and iOS, that incorporates all your favourite features with additional ones - mapping, GPS support, and alarm management
  • Secure Connect - allowing you to connect securely to IP cameras and other devices remotely, therefore increasing the flexibility of solutions we can deploy
  • Integration of SmartVis, which is our range of award-winning video analytics, providing you with far greater levels of “edge intelligence” and additional capabilities
  • Enterprise scalability – we now provide additional scalability, performance and ease of administration for enterprise-grade user

What changes have been made to the EdgeVis architecture?

EdgeVis Encoders
As well as supporting all existing TVI encoders, EdgeVis introduces a number of new encoders, including a new HD-IP150 and updated mobile encoders that support body-worn cameras. For more details on this please see our technologies page.

EdgeVis Server
A refinement on TVI Server, the EdgeVis Server application introduces an updated management interface that unifies account and licence management, plus a range of performance and resilience features.

EdgeVis Client
EdgeVis introduces a new unified viewing client across Windows, iOS and Android that provides a common look and feel on all platforms.

What products can I buy going forward?

Please see our EdgeVis Live range as detailed above. For more information on the encoders please see the TVI technology page.

How do I upgrade from TVI to EdgeVis Live?

  1. Decide what TVI devices will be transitioned to EdgeVis
    Before continuing, calculate the numbers and types of encoders you will want to support on your server.
  2. Sign up for a new EdgeVis support contract
    Access to the EdgeVis software will only be provided to those customers with an active support contract.
  3. Obtain a new EdgeVis licence key
    You will be issued a new licence pack to install onto your existing TVI Server in preparation of the upgrade. This will mirror the devices you specified in Step 1 and will ensure you do not lose any functionality.
  4. Install the new EdgeVis Server
    Download and install the new EdgeVis Server software. All existing accounts are preserved and your server will continue to operate as before. For IP Series and Q Series (MiniCam) devices there is a final step, which is to assign manually the new EdgeVis licences, using Web Manager.
  5. Install the new EdgeVis viewing clients
    While existing clients will continue to have functionality, you should install the new EdgeVis Client to take advantage of the new EdgeVis capabilities.

Customers who decide not to transition to EdgeVis can continue to operate their TVI Server with its current capabilities. New purchases will only be available with EdgeVis licences and must operate on an EdgeVis server.  For more information please download the customer-information pack.
